D830 Series
8 T1/E1/J1 ports;
Up to 256 channels in E1 mode or 192 channels in T1/J1 modes;
Support protocols PRI, SS7, R2;
Lifetime warranty!
Request a Quote-
Specifications
OpenVox D830 Series is now the leading 8 port T1/E1/J1 PCI-E card in the open source industry. It supports up to 256 channels in E1 mode or 192 channels in T1/J1 modes.It takes full advantage of Octasic® Hardware Echo Cancellation Module to deliver the superior voice quality over T1, E1, and J1 interface.
The D830 Series supports T1, E1, and J1 environments and is selectable on a per-card or per-port basis. DE830E is supposed to be the most advanced 8 port T1/E1/J1 asterisk® card with superior quality in the open source community. The leading innovation ensures users to adjust the interrupts frequency to reduce the CPU load up to 70% and adjust the interrupt number to avoid interrupt number sharing or conflict.
D830 Series supports industry standard telephony and data protocols, including Primary Rate ISDN (both N. American and Standard Euro) protocol families for voice, PPP, Cisco, HDLC, and Frame Relay data modes. Both line-side and trunk-side interfaces are supported.
D830 Series works with Asterisk®, Elastix®, FreeSWITCH®, PBX in a Flash, trixbox®, Yate® and IPPBX/IVR projects as well as other Open Source and proprietary PBX, Switch, IVR, and VoIP gateway applications.
Target Applications
- Voice-over Internet Protocol (VoIP) Services
- Complex IVR Trees
- "Meet-Me" Bridge Conferencing
- Calling Card Platforms
- VoIP Gateways (support SIP, H.323, and IAX)
- Legacy PBX/IVR Services
- Voice/Data Router (replace expensive routers)
- PRI/Switch Compatibility - Network or CPE
Technical Specifications
- 8 T1/E1/J1 ports with PCI-E interface for high performance voice and data applications
- RJ48 connector
- FPGA design, upgradeable firmware onsite
- Power Consumption: 3.6W Minimum, 4.9W Maximum at 3.3 V or 5 V.
- Operation temperature: 0°C to 50°C
- Dimension: 2U Form factor: 12*6.4*1.8cm
Minimum Hardware Requirement
- 800-Mhz Pentium III
- 128MB RAM
PRI Switch Compatibility
- EuroISDN (PRI or PRA) - Q.931/Q.921
- Network or CPE
- AT&T 4ESS
- National ISDN 2
- CAS Voice Modes
- DMS 100
- Lucent 5E
Optional Octasic® DSP Echo Cancellation Module—EC2128
- 128ms tail/channel (on all channel densities)
- Octasic® Music Protection
- Adaptive Noise Reduction
- Automatic Level Control (G.169)
- Field upgradeable algorithm
- V.25 / V.8 answer tone (w/ and w/o phase reversal)
- DTMF as per Q.24
- No CPU load as a result of echo cancellation.
- Does not increase the physical size of the card, and no additional slot is required
- EC2128 power consumption: 0.33W/3.5W
- Operation temperature: 0 to 50°C
Operating Systems
- Linux all versions, releases and distributions in 1.0 up
D830 Series Digital Cards Product Model D830E D830P DE830E DE830P Storage temperature -65~125°C -40~75°C Weight 94g 98g 104g 108g EC module no yes Interface PCI-E PCI PCI-E PCI -
Features
- Industry 1st adjustable interrupt routing design
- Interrupts frequency adjustment
- Compatible with All Commercially Available Motherboards
- 8 T1/E1/J1 ports with PCI-E interface for high performance voice and data applications
- Octasic® Hardware Echo Cancellation Module Available
- 3-Month "No Questions Asked" Return Policy
- Lifetime warranty
